| Type of Product | High Speed Laser Engraver |
| Weight | 4.45 Kg (9.81 lb) |
| Input Power | 100-120 V AC, 50/60 Hz |
| Output Power | 24 V/3.5 A |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
High Speed Laser Engraver |
Weight |
4.45 Kg (9.81 lb) |
Input Power |
100-120 V AC, 50/60 Hz |
Output Power |
24 V/3.5 A |
Country of Origin |
India |
Compatible Material |
Cutting: Paper, Wood, Leather, MDF, Felt, Some Dark Opaque Acrylic | Engraving: Paper, Wood, Leather, Coated Metal, Some Dark Opaque Acrylic |
Name of Manufacturer/Packer/Importer |
Protomont Technologies LLP |
File Format |
SVG, DXF, JPG, JPEG, PNG, BMP, etc (Supported) |
Working Speed |
4000 mm/s (157.48 ips) [Max.] |
Dimension (inch) |
7.05x9.25x13.15 |
Laser power |
10 W (Diode Laser) |
Working Area |
115x115 mm (4.53x4.53 inch) | 400x115 mm (15.75x4.53 inch) with Extension |
Model Name |
F1-Lite |
Dimension (mm) |
179x235x334 |
Software compatibility |
xTool Creative Space, LightBurn |
Connectivity |
USB, Wi-Fi |
Framing Mode |
Rectangle Framing, Outline Framing |
Preview Method |
High-Speed Light Live Preview |
Function |
Laser Engraving, Laser Cutting |
Assembly |
Pre-Assembled |
Laser Spot Size |
0.08x0.06 mm (0.00315x0.00236 inch) |
Focus Mode |
Auto Focus, Manual Focus (Two Dots Alignment) |
Maximum Rotary Engraving Diameter |
113 mm (4.45 inch) |
Motion Accuracy |
0.00199 mm (0.000078 inch) |
Maximum Cutting Capacity |
Basswood: 8 mm (0.32 inch) in Multiple Passes | Acrylic: 6 mm (0.24 inch) in Multiple Passes |
Supported OS |
Android, iOS, Windows, macOS |
Safety Class |
Class 4 Laser Safety |
Maximum Processing Height |
113 mm (4.45 inch) |
