Ships within 25 days
Outer Diameter
Model No
View
View
View
View
| Inner Diameter | 12 mm |
| Width | 11 mm |
| Outer Diameter | 28 mm |
| Type of Product | Thrust Ball Bearing |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Inner Diameter |
12 mm |
Width |
11 mm |
Outer Diameter |
28 mm |
Type of Product |
Thrust Ball Bearing |
Model No |
51201 |
Country of Origin |
Japan |
Load direction |
radial |
Chamfering Size r (mm) |
0.6 (minimum) |
Outer ring type |
flat |
No. of Track Trains |
Single row |
Shield Shape |
Open type |
Race ring shape |
Thrust ball bearing |
Body Material |
High carbon chromium bearing steel |
Rolling element material |
High carbon chromium bearing steel |
JIS grade |
0 |
Basic dynamic load rating Ca (N) |
13200 |
Basic static load rating Coa (N) |
19000 |
Monotaro ID |
347164 |
Dimension d1 (Φmm) |
28 (maximum) |
Grease Limiting Speed (RPM) |
5600 |
Oil Limiting Speed (RPM) |
8000 |
Reference mass (g) |
34 |
Import Country |
Japan |
Name of Manufacturer/Packer/Importer |
NTN Corp. |
