| Application | Industrial Control System |
| Frequency | 47 ~ 63 Hz |
| Type of Product | Dual Output Analog Signal Converter |
| Weight | 240 g |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Application |
Industrial Control System |
Frequency |
47 ~ 63 Hz |
Type of Product |
Dual Output Analog Signal Converter |
Weight |
240 g |
Model No |
AS845-325 |
Maximum Input Current |
30 mA |
Mounting Type |
35 mm DIN rail |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
M/s Anand Syndicats |
Maximum Input Voltage |
100 V |
Power Indicator |
Power on LED |
Auxiliary Ripple |
Less than 1% of Span |
Operating Ambient Temperature |
0~50°C |
Auxiliary Range |
90 ~ 270 V AC |
Storage Ambient Temperature |
-20°C to 85°C |
Output 1 |
0 - 10 V DC |
Output 2 |
0 - 10 V DC |
Adjustment Type |
Zero & Span On Front For Each Output |
Features |
4 Point Isolation of 2 KV AC, Low Ripple & Noise, Economical, High Reliability, Compact |
Output Specifications |
0-10 V DC, 20 mA maximum 4-20 mA, 500 Load maximum 0-5 V DC, 20 mA maximum |
Input Impedance |
10 V : 100 K ohm & 20 mA : 10 ohm |
Overload Protection |
Output short circuit current 30 mA max |
Nominal Voltage |
230 V AC/DC |
Input Temperature |
0 to 600° C |
Input Type |
RTD – PT100, 2 or 3 Wire |
Humidity |
95% RH Non-Condensing |
