Showing 40 out of 102 products
Control Output : 5 A @ 230 VAC
Type of Product : Timer
Application : Timer provide the basic switching or controlling function and also provide the timing functions in the circuit.
Dimension (mm) : 48x48X79 mm
Features : Multi-function multi-range.Front knob for time range and time scale.Slim, space saving design.Universal power supply
Operating Temperature : 0 to 50°C
Storage Temperature : -20 to 75°C
Warranty Duration : 12 months as per Selec
Accuracy : ±5% of F.S
Power Consumption : 3.3 VA
Control Output : 3 A at 250 VAC
Type of Product : Analog Timer
Weight (g) : 100 g
Run Up Time range : 0.05 s to 100 hr
Ambient Humidity : 35 to 85%
Storage Temperature : -25 to 65?C
Reset Time : <100 ms
Accuracy : ?5% of F.S
Plug Type : 8 pin plug type
Type of Product : Universal Range Digital Timers
Range : 0-9999 Sec, Min, Hour Selectable, On Delay, Off Delay, Cyclic Timer
Voltage : 100-270 V AC
Output : 1R2C/O
Type of Product : Digital Presettable Timer
Time Setting : Time Setting by Thumb Wheel
Weight (g) : 4 Kg
Display : Single Display: 7 Segment, 3 Digit, 14.22 mm, Red LED Display.
Features : Microcontroller Based Digital Presettable Timer. Dip Switch For Range And Mode Selectable.
Function : Delayed ON / Instant ON
Power Supply : 230V AC
Power Consumption : 3.3 VA
Type of Product : Analog Timer
Weight (g) : 100 g
Run Up Time range : 0.05 s to 100 hr
Rated Voltage : 12 V
Ambient Humidity : 35 to 85%
Operating Temperature : -10 to 55?C
Storage Temperature : -25 to 65?C
Reset Time : <100 ms
Accuracy : ?5% of F.S
Plug Type : 11 pin plug type
Type of Product : Din Rail Display Analog Timer
Dimension : 90x22.5x72 mm (HxWxD)
Type of Product : On Delay / Interval Analog Timer
Application : Industrial Control System
Mounting Type : DIN Rail / Base Mount
Contact Rating : 5 A@230 V AC / 24 V DC, Resistive
Termination : Screw Type, for 2.5 mm sq. Wire
Protection Level : IP40 for Housing, IP20 for Terminals, Finger Safe Terminals
Power Indicator : LED Status Indicator : Power ON, Relay ON
Humidity : 85% RH
Operating Ambient Temperature : 0~55°C
Storage Ambient Temperature : -20°C to 85°C
Power Consumption : 10 VA Max.
Type of Product : Star Delta Analog Timer
Application : Industrial Control System
Mounting Type : DIN Rail / Base Mount
Accuracy : Setting : ±5% of Full Scale, Repeat : ±0.5% or 50 m sec of Full Scale.
Weight : 110 g
Contact Rating : 5 A@230 V AC
Termination : Screw Type, for 2.5 mm sq. Wire
Protection Level : IP40 for Housing, IP20 for Terminals, Finger Safe Terminals
Output Contact : SPDT (1 C/O) each for Star & Delta
Power Indicator : LED Status Indicator : Star Relay ON, Delta Relay ON
Humidity : 95% RH Non Condensing
Operating Ambient Temperature : 0~55°C
Storage Ambient Temperature : -20°C to 85°C
Isolation : Supply Terminals – Contacts : 1.5 kV, 1 min.
Contact Set 1 – Contact Set2 : 1.5 kV, 1 min.
Time Range : Star Run up time range 0-30 sec, 0-60 sec (Switch Selectable)
Change over time : 50 m sec or 100 m sec (Switch Selectable)
Power Consumption : 6 VA Max.
Type of Product : On Delay / Interval Analog Timer
Application : Industrial Control System
Mounting Type : Panel Mount
Contact Rating : 5 A@230 V AC / 24 V DC, Resistive
Termination : Screw Type, for 2.5 mm sq. Wire
Protection Level : IP40 for Faceplate
Power Indicator : LED Status Indicator : Power ON, Relay ON
Humidity : 95% RH Non Condensing
Operating Ambient Temperature : 0~55°C
Storage Ambient Temperature : -20°C to 85°C
Power Consumption : 6 VA Max.
Type of Product : On Delay Analog Timer
Application : Industrial Control System
Mounting Type : DIN Rail / Base Mount
Accuracy : Setting : ± 5% of Full Scale, Repeat : ± 0.5% or 50 m sec
Weight : 100 g
Contact Rating : 5 A@230 V AC / 24 V DC, Resistive
Termination : Screw Type, for 2.5 mm sq. Wire
Protection Level : IP40 for Housing, IP20 for Terminals, Finger Safe Terminals
Output Contact : SPDT (1 C/O)
Power Indicator : LED Status Indicator : Power ON, Relay ON
Humidity : 85% RH
Operating Ambient Temperature : 0~55°C
Storage Ambient Temperature : -20°C to 85°C
Isolation : Supply Terminals – Contact : 1.5 kV, 1min.
Power Consumption : 2 VA Max.
Type of Product : On Delay / Interval Analog Timer
Application : Industrial Control System
Mounting Type : Panel Mount
Accuracy : Setting : ± 5% of Full Scale, Repeat : ± 0.5% or 50 m sec of Full Scale.
Weight : 100 g
Contact Rating : 5 A@230 V AC / 24 V DC, Resistive
Termination : Screw Type, for 2.5 mm sq. Wire
Protection Level : IP40 for Faceplate
Output Contact : DPDT (2 C/O)
Power Indicator : LED Status Indicator : Power ON, Relay ON
Humidity : 95% RH Non Condensing
Operating Ambient Temperature : 0~55°C
Storage Ambient Temperature : -20°C to 85°C
Isolation : Supply Terminals – Contacts : 1.5 kV, 1 min.
Contact Set 1 - Contact Set 2 : 1.5 kV, 1 min.
Power Consumption : 2 VA Max.
Type of Product : Forward-Pause-Reverse Analog Timer
Application : Industrial Control System
Model No : TAFR-8M-U
Mounting Type : DIN Rail / Base Mount
Accuracy : Setting : ±5% of Full Scale, Repeat : ±0.5% or 50 m sec of Full Scale.
Weight : 120 g
Contact Rating : 5 A@230 V AC / 24 V DC, Resistive
Termination : Screw Type, for 2.5 mm sq. Wire
Protection Level : IP40 for Housing, IP20 for Terminals, Finger Safe Terminals
Output Contact : 1 C/O (SPDT) each for Forward & Reverse
Power Indicator : LED Status Indicator : Power ON, Relay ON
Humidity : 95% RH Non Condensing
Operating Ambient Temperature : 0~55°C
Storage Ambient Temperature : -20°C to 85°C
Isolation : Supply Terminals – Contacts : 1.5 kV, 1 min
Contact Set 1 – Contact Set 2 : 1.5 kV, 1 min
Time Range : Run Time
1/2/4/8 sec / min (Switch Selectable)
Pause Time
1/2/4/8/10/20/40/80 sec / min (Switch Selectable)
Power Consumption : 2.5 VA Max.
Type of Product : True Power OFF Analog Timer
Application : Industrial Control System
Mounting Type : DIN Rail / Base Mount
Accuracy : Setting : ±5% of Full Scale, Repeat : ± 0.5% or 50 m sec
Weight : 120 g
Supply Voltage : 110 – 240 V AC/DC
Contact Rating : 2.5 A@230 V AC
Termination : Screw Type, for 2.5 mm sq. Wire
Protection Level : IP40 for Housing, IP20 for Terminals, Finger Safe Terminals
Output Contact : DPDT (2 C/O)
Humidity : 95% RH Non Condensing
Operating Ambient Temperature : 0~55°C
Storage Ambient Temperature : -20°C to 85°C
Isolation : Supply Terminals – Contacts : 1.5 kV, 1 min
Contact Set 1 – Contact Set 2 : 1.5 kV, 1 min
Power Consumption : 2 VA Max.
Type of Product : Cyclic ON First Or OFF First Analog Tmer
Application : Industrial Control System
Model No : TACY-10H-U
Mounting Type : DIN Rail / Base Mount
Accuracy : Setting : ±5% of Full Scale, Repeat : ±0.5% or 50 m sec of Full Scale.
Weight : 120 g
Contact Rating : 5 A@230 V AC / 24 V DC, Resistive
Termination : Screw Type, for 2.5 mm sq. Wire
Protection Level : IP40 for Housing, IP20 for Terminals, Finger Safe Terminals
Output Contact : DPDT (2 C/O)
Power Indicator : LED Status Indicator : Power ON , Relay ON
Humidity : 95% RH Non Condensing
Operating Ambient Temperature : 0~55°C
Storage Ambient Temperature : -20°C to 85°C
Isolation : Supply Terminals – Contacts : 1.5 kV, 1 min
Contact Set 1 – Contact Set 2 : 1.5 kV, 1 min
Time Range : ON Time
0 – 1 sec / min / hour, 0 – 10 sec / min / hour (Switch Selectable)
OFF Time
0 – 1 sec / min / hour, 0 – 10 sec / min / hour (Switch Selectable)
Application : Industrial
Usage For : Controlling Equipment, Monitoring Processes, And Ensuring Safety
Standard Compliance : CE
Pack of : 100 Pcs
Page 1 of 3 results
| Product Name | Specifications | Expected Price | Dispatch Time | Discount |
|---|---|---|---|---|
| Shavison Star Delta Analog Timer SPDT (1 C/O) each for Star & Delta 230 VAC, 10 VA Max. (Contact), TASD-60S-230AC | Accuracy Setting : 5% of Full Scale, Repeat : 0.5% or 50 m sec of Full | Contact Rating 5 A@230 V AC | ₹650 | 7 days | -- |
| Autonics Analog Timer With 8 Pin Plug -AT8N | Accuracy ?5% of F.S | Ambient Humidity 35 to 85% | ₹2,359 | 4 days | -- |
| Shavison On Delay / Interval Analog Timer DPDT (2 C/O) 12 - 240 V DC, 2 VA Max. (Contact), TADU-60M-U | Accuracy Setting: 5% of Full Scale, Repeat: 0.5% or 50 m sec of Full | Contact Rating 5 A@230 V AC / 24 V DC, Resistive | ₹830 | 8 days | -- |
| Selec Panel Mounting Analog Timer - 55ES-P8-230 - 48x48mm | Accuracy 5% of F.S | Ambient Humidity 95% RH | ₹884 | 24 hrs | 20% OFF |
| Selec Panel Mounted Timer with On Delay / Interval Modes 3sec to 60min, 55ES-T-230 | -- | ₹754 | 24 hrs | 23.37% OFF |
Explore the world of precise time control with our analogue timers at Industrybuying. An analogue timer is an essential component in industrial automation, providing accurate and reliable timing for various processes. Whether you need a cyclic timer or a 24-hour analogue timer, we offer a diverse range to suit your requirements.
- Versatile Functionality : Our analogue timers cater to a variety of applications, ensuring seamless integration into your industrial automation setup.
- Digital Precision : Experience precise time management with our state-of-the-art analogue clock timers.
- Solid State Reliability : Trust in the durability and reliability of our analogue timers, designed for robust industrial use.
Explore our collection online and discover the perfect analogue Timer for your needs. Enhance your industrial automation setup with quality timing solutions. Shop now for the best analogue timer prices and elevate your time control capabilities.
An analogue timer, also known as a cyclic timer, operates through simple mechanical mechanisms, providing reliable timekeeping solutions for various applications. Here's a brief overview:
1) Clock Mechanism : The timer contains a clock mechanism, usually powered by a spring or a small electric motor, that drives the movement of the timer's hands.
2) Gear System : The clock mechanism is connected to a system of gears. These gears translate the rotational motion of the clock mechanism into the movement of the timer's hands.
3) Dial and Hands : The timer has a dial with markings representing units of time (e.g., minutes or hours) and one or more hands that indicate the current time.
4) Countdown Mechanism : An additional mechanism is used to set the desired time duration for a countdown timer. This mechanism typically involves rotating a knob or dial to set the desired time interval.
5) Release Mechanism : Once the timer reaches zero, a release mechanism is triggered. In kitchen timers, for example, this might involve a bell ringing or a mechanical switch flipping.
6) Affordable Solutions : Check out competitive analogue timer prices, making them cost-effective choices for industrial automation projects. Use them with proper electrical components and materials for more accurate results
Analogue timers find widespread application across various industries due to their reliability and simplicity. Common uses include:
a) Industrial Automation : Integral in controlling machinery and processes for enhanced efficiency.
b) Home Appliances : Used in ovens, washing machines, and other electronic devices for precise time management.
c) Outdoor Lighting : Ideal for controlling garden lights, decorative lighting, and outdoor signage.
d) Aquariums: Ensures regular operation of filters, lights, and other equipment for aquatic environments.
e) HVAC Systems : Regulates heating and cooling systems for optimal performance.
f) Photography Darkrooms : Controls exposure times during photo development.
g) Education : Employed as teaching aids for activities with specific time requirements.
These versatile devices play a crucial role in diverse settings, providing a cost-effective and user-friendly solution for time-based control.
Analogue timekeeping offers various kinds of devices designed to meet specific needs. Here are some common types of analogue time:
1) Analogue Clocks : Traditional timepieces with an hour and minute hands on a circular dial.
2) Analogue Watches : Portable timekeeping devices worn on the wrist, often with additional features like date displays.
3) Analogue Timers : Devices used to measure or control a specific duration, commonly used in industrial settings for process control.
4) Cyclic Timers : Timers that repeat a cycle of on-and-off durations, ideal for repetitive processes.
5) 24-Hour analogue Timers : Timers display time in a 24-hour format, suitable for applications requiring extended monitoring.
6) Visual analogue Timers : Timers with visual indicators offer a clear and intuitive way to track time.
Each type serves a unique purpose, providing flexibility for different applications and time-keeping preferences. You can find each of these types on our website under budget along with other useful networking devices and components.
Discover the efficiency of analogue timers with Industry Buying's extensive selection. Our analogue timers, including the 24-hour analogue Timer and visual analogue Timer online, offer unparalleled advantages in industrial automation. Explore the benefits:
i) Precision Timing : analogue timers provide accurate timekeeping for industrial processes.
ii) Reliability : Trust in the reliability of analogue clock timers for seamless operation.
iii) Cost-Effective : analogue timers, with a competitive analogue timer price, offer cost-effective solutions.
iv) Easy Integration : Seamlessly integrate analogue timers into your automation systems for enhanced efficiency.
Explore the world of industrial automation with our analogue timers, complemented by keywords like time analogue online and "analogue timer online.
a) Wide Selection : Browse a vast collection of analogue timers suitable for diverse industrial applications.
b) Competitive Prices : Find cost-effective analogue timer solutions along with other useful products like encoders without compromising on quality.
c) Convenience: Shop for analogue timers and timer switches online, saving time and effort in the procurement process.
d) Expertise : Trust Industrybuying for your industrial automation needs with our expertise in the field.
Enhance your time management capabilities with Industrybuying's analogue timers. Explore the world of industrial automation seamlessly.
